Bring drama and detail to your walls with vertical lines.
Product Details
Axon™ Cladding delivers the fine detail of painted vertical-joint timber — without the construction complexity or durability challenges that come with real timber. The panels feature evenly spaced vertical grooves (133mm or 400mm spacing) on a 9mm fibre cement sheet, with a stepped shiplap joint on long edges for fast, clean installation. Axon can be gun-nailed and cut cleanly with a circular saw using a dust-reducing fibre cement blade.
Axon suits contemporary upper-storey and ground-floor extensions, and is at home in modern, coastal, and Hamptons-influenced building styles. Vertical lines emphasise height, add textural interest, and create an immediate point of difference on external walls.
For a design that blends vertical and horizontal rhythm, consider pairing Axon with Stria™ Cladding — a great combination for mixed-material façades.
Best for Axon™ Cladding
- Upper-storey cladding on contemporary builds and extensions
- Coastal and beachy building styles that suit vertical line detail
- Hamptons, modern, and architectural residential projects
- Feature walls and entrance zones where vertical lines add height and drama
- Mixed-façade designs combining vertical Axon with horizontal Stria™
Selecting the Best Axon™ Profile
Choose your groove spacing
- 133mm spacing — finer vertical rhythm, closer to traditional VJ look; suits coastal and Hamptons styles
- 400mm spacing — bolder, more architectural; suits contemporary and minimalist designs
Choose your panel length
- 2450mm — suits standard residential floor-to-floor height with minimal waste
- 2750mm — extends coverage for taller floor heights or large feature walls
- 3000mm — ideal for two-storey applications or jumbo feature panels
- 3600mm — maximum length for tall elevations, reducing the number of horizontal joints
Choose your surface texture
- Smooth — clean, modern, takes paint very well; most popular choice
- Grained — subtle timber-grain texture; adds warmth to coastal and Hamptons designs
Why Builders and Designers Specify Axon™
- All the visual appeal of VJ timber without the shrink/swell cycle and ongoing maintenance
- Stepped shiplap joint makes installation fast and keeps lines consistent
- Can be gun-nailed — no pre-drilling required on most framing configurations
- Multiple lengths and groove spacings give genuine design flexibility in one product line
Pair with a quality wall wrap or sarking product behind Axon for best moisture management in Perth's coastal and variable climate.
Installation Notes That Prevent Callbacks
- Always use a dust-reducing fibre cement blade when cutting — protects the job and your team
- Install with a stepped shiplap — do not butt-join long edges
- Treat end cuts with sealer before installation to limit moisture ingress at cut edges
- In BAL-rated zones, confirm Axon's suitability for the BAL level with your certifier
- Follow manufacturer fixing patterns — incorrect fastener spacing is a common callback cause
Ready to order? Request a quote online and our Perth team will respond quickly.
What's the difference between Axon™ 133mm and 400mm groove spacing?
The 133mm groove spacing produces a fine, closely-spaced vertical line pattern — visually closer to traditional VJ (vertical joint) timber boarding. It suits coastal, Hamptons, and contemporary heritage styles where a detailed, rhythmic texture is desired. The 400mm spacing creates bolder, wider panels with a more architectural, minimalist look, better suited to contemporary and industrial-influenced designs. If you're unsure, the 133mm smooth is the most popular choice across residential projects in Perth.
Can Axon™ replace VJ timber weatherboard?
Axon is a popular choice for homeowners and builders who want the look of VJ or vertical-joint timber without the maintenance. Unlike timber, Axon won't shrink, swell, or rot — it holds paint longer and doesn't require the same level of ongoing sealing and repainting. It installs faster using the stepped shiplap joint and can be gun-nailed, which saves time on large facades. The Grained texture variant in 133mm most closely approximates a painted timber VJ finish.
Does Axon™ need wall wrap or sarking behind it?
Yes — Axon should always be installed with a compliant wall wrap or sarking product behind it. This manages moisture that may pass the cladding layer, satisfies NCC condensation management requirements, and is particularly important in Perth's coastal climate where humidity and salt air add to moisture load. Use a vapour-permeable wall wrap to allow the wall assembly to breathe.
Can I use Axon™ on the upper storey only and a different cladding on the ground floor?
Absolutely — this is one of the most popular design applications for Axon. Using Axon vertically on the upper storey with a horizontal product like Stria™ Cladding or
What's the largest Axon™ panel available?
The largest available Axon panel is 3600mm long (product code 404979), in the 133mm Smooth profile. This reduces the number of horizontal joints on tall walls, which is particularly valuable for two-storey facades or large feature walls where an uninterrupted vertical line is the design intent. Check availability when placing your order — contact our team to confirm stock of specific lengths.
Is Axon™ suitable for use in a BAL 29 or BAL 40 bushfire zone?
Axon's BAL suitability depends on the overall wall construction system, not just the cladding panel. You must confirm the BAL rating with your building certifier and reference the James Hardie BAL assessment documentation for Axon. In higher BAL zones (BAL 40 and BAL-FZ), the NCC requires compliant non-combustible wall systems — for those projects, ExoTec Façade™ Panel may be more appropriate as it is a fully assessed non-combustible system.
